TTX Series
TTX axes have been developed to reduce the size or eliminate the cabinet.
A close relative of the GTX, the TTX also integrates dedicated multi-bus electronics, available in two power supply versions: 100-230VAC and 12-48 VDC.
All versions mount multi-turn absolute encoders as standard and have Modbus RTU communication protocol. Otherwise, there is a choice of five different control boards: Standard I/O, Ethernet/IP, Modbus TCP, Profinet I/O, or board with 4-20mA analog input.
More info at www.cw-actuation.com
Technical Specifications
- Flange dimensions: 60×60 / 80×80 mm
- Nominal force: up to 5,897 N
- Strokes: up to 450 mm
- Linear speed: up to 847 mm/s
- Supply voltage: 100 / 200 VAC and 12/48VDC
Attributes
High force
Integrated drive
Integrated motor
IP65
Low voltage
TTX Series
TTX axes have been developed to reduce the size or eliminate the cabinet.
A close relative of the GTX, the TTX also integrates dedicated multi-bus electronics, available in two power supply versions: 100-230VAC and 12-48 VDC.
All versions mount multi-turn absolute encoders as standard and have Modbus RTU communication protocol. Otherwise, there is a choice of five different control boards: Standard I/O, Ethernet/IP, Modbus TCP, Profinet I/O, or board with 4-20mA analog input.
More info at www.cw-actuation.com
Attributes
High force
Integrated drive
Integrated motor
IP65
Low voltage
Technical Specifications
- Flange dimensions: 60×60 / 80×80 mm
- Nominal force: up to 5,897 N
- Strokes: up to 450 mm
- Linear speed: up to 847 mm/s
- Supply voltage: 100 / 200 VAC and 12/48VDC
